GX10 & GY10 Halogen & HID Lamp Holders
GX10 & GY10 Halogen & HID Lamp Holders – High-Temperature Socket Solutions
Yoeruyo's GX10 and GY10 lamp holders are engineered for halogen and high-intensity discharge (HID) lamps operating at elevated temperatures and high wattages. The GX10 and GY10 bases feature a 10mm pin pitch bayonet or pin-type retention mechanism and are commonly found in professional stage lighting, architectural accent lighting, retail display fixtures, and industrial high-bay luminaires. Our sockets are available in ceramic and high-temperature thermoplastic variants to suit the specific thermal demands of each application.
Key Technical Specifications
| Parameter | GX10 | GY10 |
|---|---|---|
| Pin Pitch | 10mm | 10mm |
| Pin Diameter | 3.0mm | 3.0mm |
| Compatible Lamp Types | Halogen PAR, HID, ceramic metal halide | Halogen PAR, HID, ceramic metal halide |
| Rated Voltage | Up to 250V AC | Up to 250V AC |
| Rated Wattage | Up to 150W | Up to 150W |
| Housing Material | Ceramic or high-temp thermoplastic | Ceramic or high-temp thermoplastic |
| Contact Material | Copper alloy, nickel plated | Copper alloy, nickel plated |
| Operating Temperature | Up to +250°C (ceramic variants) | Up to +250°C (ceramic variants) |
| Mounting | Horizontal / Vertical / Angled | Horizontal / Vertical / Angled |
| Compliance | CE, RoHS | CE, RoHS |
GX10 vs GY10 – Key Differences
GX10 and GY10 share the same 10mm pin pitch but differ in the lamp base retention geometry. GX10 uses a twist-lock (bayonet-style) retention; GY10 uses a straight push-in pin retention. The socket housing must match the lamp base type — they are not interchangeable. Always verify the lamp base designation before ordering.
Application Scenarios
- Stage & theatrical lighting – PAR and profile spotlights in entertainment venues, studios, and live event production
- Architectural accent lighting – directional halogen and HID fixtures for facade, landscape, and interior accent illumination
- Retail display & museum lighting – high-CRI halogen and ceramic metal halide lamps for merchandise and artwork display
- Industrial high-bay luminaires – HID lamps in warehouse, factory, and sports facility high-bay fixtures
- OEM luminaire manufacturing – production-line socket integration for professional and architectural luminaire manufacturers
Why Choose Yoeruyo GX10 / GY10 Lamp Holders
- ✅ Ceramic variants for extreme heat – ceramic housing withstands continuous temperatures up to +250°C for high-wattage HID applications
- ✅ Secure lamp retention – twist-lock (GX10) and push-pin (GY10) mechanisms prevent lamp displacement under vibration
- ✅ High-current contacts – copper alloy contacts rated for up to 150W continuous load
- ✅ Bulk & OEM supply – flexible MOQ and tiered pricing for luminaire manufacturers and electrical distributors
- ✅ CE & RoHS compliant – meets EU Low Voltage Directive and RoHS requirements for lighting components
Buying Guide – Selecting the Right Socket
- GX10 vs GY10 – confirm the lamp base retention type (twist-lock = GX10; push-pin = GY10) before ordering
- Ceramic vs thermoplastic – use ceramic sockets for lamps above 75W or in enclosed fixtures with limited airflow; thermoplastic is suitable for lower-wattage open fixtures
- Wattage rating – confirm the socket's rated wattage meets or exceeds the lamp wattage; do not exceed the rated load
- Mounting orientation – horizontal for ceiling downlights; vertical for wall-wash; angled for directional accent fixtures
- Wire gauge – use 1.0mm² to 1.5mm² (AWG 18–16) silicone-insulated wire for high-temperature applications near the lamp
Frequently Asked Questions
What is the difference between GX10 and GY10?
GX10 and GY10 share the same 10mm pin pitch but differ in retention mechanism. GX10 uses a twist-lock (bayonet-style) action; GY10 uses a straight push-in pin. The socket must match the lamp base type — they are not interchangeable.
Do I need a ceramic socket for halogen lamps?
For halogen lamps above 75W or in enclosed fixtures with restricted airflow, ceramic sockets are strongly recommended due to the high operating temperatures generated near the lamp base. For lower-wattage open fixtures, high-temperature thermoplastic sockets are acceptable.
Are these sockets compatible with LED retrofit lamps?
LED lamps in GX10 and GY10 bases are available from some manufacturers. These are typically lower-wattage and generate significantly less heat, so thermoplastic sockets are generally suitable. Confirm the LED lamp's base type and wattage before specifying the socket.
What wire insulation is recommended for high-temperature installations?
Silicone-insulated wire (rated to +180°C or higher) is recommended for connections near high-wattage halogen and HID lamp sockets. Standard PVC-insulated wire is not suitable for temperatures above +70°C.
Do you offer bulk pricing for OEM luminaire production?
Yes. Yoeruyo offers tiered pricing for orders of 100 units or more. Contact us for volume quotations, custom lead wire configurations, and OEM packaging options.
