Description

SPECIFICATIONS

Body Plating: Nickelplated

Brand Name: DexMRtiC

Cable Type: RG58 RG142 RG316 RG174

Certification: CE

Choice: yes

Does it include a Battery?: No

Does it include wireless functionality?: No

EU LVD Voltage: Low voltage: Below 50Vac or 75Vdc

Gender: male female

High-concerned chemical: none

Impedance: 50 Ohm

Material: Brass

Model Number: N Male Connector

Mounting: Cable mount

Origin: Mainland China

Product type: N type connector

Style: Straight

Voltage: 24V

semi_Choice: yes






1PC /4PC N Crimp Plug male Jack Female bulkhead RF coax connector crimp for LMR195 RG58 RG316 RG174 straight Copper with drawing wholesale






Description:


N Type is used in connection with RF coaxial cable in radio

instrument, communication equipment, microwave test and ground launch

system at vibration and inclement weather circumstance.


Applicable Standard:

MIL-C-39012

CECC 22210

IEC-60169-16


Major Technical Characteristics

MATERIAL & PLATING

Temperature Range:

-55~+155°C(PE Cable -40~+85°C)

Impedance:

50Ω

Body

brass

Nickel plated

Frequency Range:

DC~4GHz

Working Voltage:

1000V r.m.s at sea level

Resilient contact

Beryllium-copper

Gold plated

Withstanding Voltage:

2500V r.m.s at sea level

Contact resistance:

a)Center Contact   ≤1m Ω

b)Outer Contact ≤1m Ω

Pin contact

brass

Gold plated

Insulation resistance:

≥5000MΩ

Socket contact

Beryllium-copper

Gold plated

Center Conductor retention force:

≥0.56N

insulator

PTFE


Vibration

100m/S2(10~500Hz),10g

Coupling nut retention force

450 N

Crimp ferrule

Copper alloy

Nickel or gold plated

Disengagement force

8~63 N

Voltage Standing Wave Ratio:

Straight  ≤1.15/ 6GHz

Right angle ≤1.25/6GHz

O-ring sealing

silicone rubber


Durability(mating):

≥500times(cycles)
