SPECIFICATIONS

Battery Included: no

Brand Name: HoldPeak

Choice: yes

DIY Supplies: Electrical

Dimensions: 207*75*37mm

Display Type: Digital Only

HOLDPEAK Model: HP-870P

High-concerned chemical: none

Measuring Capacitance Range: 51.2nF~100μF

Measuring Current Range: 200A/400A/1000A

Measuring Inductance Range: /

Measuring Resistance Range: 400Ω~40MΩ

Measuring Voltage Range: AC: 750V; DC: 1000V

Model Number: 870P

Operating Temperature: /

Origin: Mainland China

Semi-finishedproduct: No

Weight: 0.64kg

semi_Choice: yes

【True RMS & Wide Measurement Range】 Equipped with True RMS technology, it accurately measures AC/DC currents up to 1000A and voltages up to 600V, ensuring reliable data for various electrical systems.

【Comprehensive Power Analysis】 Specifically designed for power testing, it measures Active Power (kW), Reactive Power (kVar), Apparent Power (kVA), and Power Factor (PF), providing a complete analysis of electrical efficiency.

【Energy (kWh) Accumulation】 Features an Active Energy (kWh) function to track power consumption over time, with a maximum measuring time of 99 hours and 99 minutes, ideal for energy auditing and billing estimates.

【Advanced Data Management】 Includes a Data Hold function to freeze readings on the LCD, Max/Min recording to capture signal fluctuations, and a Backlight for clear visibility in low-light environments.

【Multi-Function Versatility】 Supports Frequency (Hz) measurement (40-250Hz) and Temperature testing (with included thermocouple), making it a versatile tool for HVAC, industrial, and electrical maintenance tasks.

Product Specifications

Display: Multi-function LCD, Max reading 9999

Sampling Rate: 3 times per second

Power Supply: 9V battery (6F22), consumption approx. 8mA

Auto Power Off: Approx. 15 minutes (disabled during Active Energy measurement)

Backlight: White color

Operating Temperature: 0°C ~ 40°C (32°F ~ 104°F), <85% RH

Storage Temperature: -10°C ~ 50°C (14°F ~ 122°F), <85% RH

Safety Standard: IEC 61010 CAT. III 600V, CAT. IV 300V
