10pcs 2.0mm PH6.35 Straight Female Header Double Row Vertical 2X2/3/4/5/7/8-20/40P PC2.8 1U Gold-plate PCB Pin Socket Connector
2X20
$26.78
Sale price
$26.78
Regular price
$0.00
Skip to product information
10pcs 2.0mm PH6.35 Straight Female Header Double Row Vertical 2X2/3/4/5/7/8-20/40P PC2.8 1U Gold-plate PCB Pin Socket Connector
$26.78
Sale price
$26.78
Regular price
$0.00
Description
SPECIFICATIONS
Brand Name: E-SIMPO
Certification: RoHS
Does it include a Battery?: No
Does it include wireless functionality?: No
EU LVD Voltage: Low voltage: Below 50Vac or 75Vdc
High-concerned chemical: None
Model Number: PH6.35 2.0mm female header
Origin: Mainland China
Voltage: 5 V 12 V 20 V 30 V
10pcs 2.0mm PH6.35 Straight Female Header Double Row Vertical 2X2/3/4/5/7/8-20/40P PC2.8 1U Gold-plate PCB Pin Socket Connector
Pin-Pin Distance/Pitch: 2.0mm
Row Qty: Double Row, 2X2-2X40Positions
type:Right angle
Current Rating: 3Amps
Insulator Resistance: 5000Megohms min
Dielectric Withstanding: AC 500V
Operating Temperature: -40-105 Celsuis Degree
Contact Material: Phosphor bronze
Finish: Gold Flash
Tolerance: +/-0.2mm
