Description

SPECIFICATIONS

Brand Name: DexMRtiC

Certification: CE,FCC,RoHS

Choice: yes

Does it include a Battery?: No

Does it include wireless functionality?: No

EU LVD Voltage: Low voltage: Below 50Vac or 75Vdc

Gender: Female Jack

High-concerned chemical: none

Impedance: 50 Ohm

Material: Brass

Model Number: N Connector

Mounting: Chassis

Origin: Mainland China

Plating: Nickelplated

Product type: N type panel mount

Style: Panel mount with solder cup

Voltage: none

is_customized: Yes

semi_Choice: yes

Description:

Product Type:N type panel mount

Gender:Female Jack

Style:Panel mount with solder cup

Plating:Nickelplated

Mounting:Chassis

Material:Brass

Status:New

Impedance:50Ohm

is_customized:Yes

N Type is used in connection with RF coaxial cable in radio

instrument, communication equipment, microwave test and ground launch

system at vibration and inclement weather circumstance.

Applicable Standard:

MIL-C-39012

CECC 22210

IEC-60169-16

Major Technical Characteristics		MATERIAL & PLATING
Temperature Range:	-55~+155°C(PE Cable -40~+85°C)
Impedance:	50Ω	Body	brass	Nickel plated
Frequency Range:	DC~4GHz
Working Voltage:	1000V r.m.s at sea level	Resilient contact	Beryllium-copper	Gold plated
Withstanding Voltage:	2500V r.m.s at sea level
Contact resistance:	a)Center Contact ≤1m Ω b)Outer Contact ≤1m Ω	Pin contact	brass	Gold plated
Insulation resistance:	≥5000MΩ	Socket contact	Beryllium-copper	Gold plated
Center Conductor retention force:	≥0.56N	insulator	PTFE
Vibration	100m/S2(10~500Hz),10g
Coupling nut retention force	450 N	Crimp ferrule	Copper alloy	Nickel or gold plated
Disengagement force	8~63 N
Voltage Standing Wave Ratio:	Straight ≤1.15/ 6GHz Right angle ≤1.25/6GHz	O-ring sealing	silicone rubber
Durability(mating):	≥500times(cycles)
