SPECIFICATIONS

Brand Name: NONE

Certification: CE

Choice: yes

Does it include a Battery?: No

Does it include wireless functionality?: No

EU LVD Voltage: Low voltage: Below 50Vac or 75Vdc

High-concerned chemical: none

Model Number: RJ45 Socket

Origin: Mainland China

Voltage: 220 V

material: zinc ally

semi_Choice: yes

waterproof: IP65

Product size manual measurement, please allow a little error,Due to the shooting lighting effect, the color will also have a little difference, please have received the actual goods for the standard,if you mind, please do not buy, thank you!
Connecting mode: Plug/unplug,
Protection level: IP45
Cable specification: 0.15 mm2 ~ 0.2 mm2 /26~24 AWG
Diameter range: Φ5.5mm ~Φ7mm
Contact diameter×Qty: 8
Current rating(A): 1.5A
Operating voltage(AC.V.rms): 500V
Withstand voltage(AC.V)1min: 2500V
Contact resistance: <1mΩ
Insulation resistance: >500MΩ
Durability: ≥500 mating&unmating cycles
Temperature rating: -40°C~80°C
Method of connecting cable: Solder
Prevent the combustion level: UL94-V0
Temperature rise: 20A per contact at 30°C, 25A per contact at 40°C, 30A per contact at 50°C.

Material:
Shell∈sulated parts: High performance engineering plastics
Hardware metal: Zinc alloy(pearl hard chromium)
Contact pin: Copper alloy(gold-plated)
Spring: Stainless steel
Sealing: Silica gel

Main characteristics:
- Sealed against dust and fluid (IP65)
- Vibration resistance,impact resistance,stretching resistance
- With one hand, can quickly insert or pull out

Application industries:
- Stage equipment - The smart grid
- Medical equipment - Server
- Solar energy equipment - Ship equipment
- Electric power equipment - Vehicle equipment
- Communications equipment

- Heavy machinery
