SPECIFICATIONS

Brand Name: NONE

Choice: yes

Display Mode: N/A

High-concerned chemical: none

Model Number: 1602

Origin: Mainland China

Resolution: 16*2

Type: Character

is_customized: Yes

Pin interface specificao table

Numbers symbols pin pin that Numbers symbols that

Foot 1: for to power VSS.
Foot 2: VDD take 5 V is power.
Foot 3: VL for LCD ctrast the adjustment, and then when the power is the weakest ctrast, grounded ctrast the highest, and the ctrast .Through high can produce the "ghost", when used, can pass a 10 K adjust potenometer ctrast.
Foot 4: RS for registers choice, high elric usuay choose data registers, low elric usuay choose itruc register.
Foot 5: R/W signal lines for reng and wring, high elric usuay are read opera, low elricity at ordinary mes for wr opera. When the RS and the R/W comm For low elricity can be written itruco at ordinary mes, or displays address, when RS for low level R/W high power for at ordinary mes can read busy signal, and when RS for high level R/W for low elricity data can be written at ordinary mes.
Foot 6: E end to make can end, when E is driven by high level jump into low elricity at ordinary mes, LCD module execuve order.
Foot 7 to 14 : D0 ~ D7 for eight two- - way data cables.
Foot 15: back light posive.
Foot 16: back light negave.

Features: LCD display module with blue backlight.

Wide viewing angle and high ctrast.
Built-in industry standard HD44780 equivalent LCD ctroer.
Commly used in: copiers, fax hines, laser printers, industrial test equipment, networking equipment such as routers and storage devices.
LCM type: Characters
Can display 2-lines X 16-characters.
Voltage: 5V DC.
Module dimei: 80mm x 35mm x 11mm.
Viewing area size: 64.5mm x 16mm
