SPECIFICATIONS

Application: Breadboard

Brand Name: SZYTF

Condition: New

Dissipation Power: .

High-concerned chemical: none

Operating Temperature: -40°C ~ +85°C

Origin: Mainland China

Package: Other

Quantity: 1

Supply Voltage: 2.7V - 5.5V

Type: Voltage Regulator

is_customized: Yes

Description

This 8-bit (octal) noninverting bus transceiver contains two separate supply rails; B port has VCCB, which is set at 3.3 V, and A port has VCCA, which is set at 5 V. This allows for translation from a 3.3-V to a 5-V environment, and vice versa.

The SN74LVC4245A device is designed for asynchronous communication between data buses. The device transmits data from the A bus to the B bus or from the B bus to the A bus, depending on the logic level at the direction-control (DIR) input. The output-enable (OE) input can be used to disable the device so the buses are effectively isolated. The control circuitry (DIR, OE) is powered by VCCA.

The SN74LVC4245A device terminal out allows the designer to switch to a normal all-3.3-V or all-5-V 20-terminal SN74LVC4245 device without board re-layout. The designer uses the data paths for pins 2-11 and 14-23 of the SN74LVC4245A device to align with the conventional '245 terminal out.

Bidirectional Voltage Translator
5.5 V on A Port and 2.7 V to 3.6 V on B Port
Control Inputs VIH/VIL Levels Are
Referenced to VCCA Voltage
Latch-Up Performance Exceeds 250 mA
Per JESD 17
ESD Protection Exceeds JESD 22
- 2000-V Human-Body Model
- 200-V Machine Model
- 1000-V Charged-Device Model
