2000W-3000W Iron-Silicon-Aluminum Inductor SPWM Filter MLCI Sine Wave Inverter Filter Inductance PFC Inductance
0.65MH 18.0A
$124.74
Sale price
$124.74
Regular price
$0.00
Skip to product information
2000W-3000W Iron-Silicon-Aluminum Inductor SPWM Filter MLCI Sine Wave Inverter Filter Inductance PFC Inductance
$124.74
Sale price
$124.74
Regular price
$0.00
Description
SPECIFICATIONS
Brand Name: NONE
Certification: NONE
Choice: yes
High-concerned chemical: none
Model Number: 2000W
Origin: Mainland China
is_customized: Yes
semi_Choice: yes
2000W-3000W Iron-Silicon-Aluminum Inductor SPWM Filter MLCI Sine Wave Inverter Filter Inductance PFC Inductance
Professional for the sinusoidal inverter output AC filter design, with large current strong
anti-saturation characteristics full current continuous working temperature rise low; Very
suitable for SPWM filter output, can be used for EG8010 TDS2285 and other sine wave chip
single-polarity sine wave and bipolar sine wave filtering.
High quality high temperature enameled pure copper wire material
0.35MH~0.65MH Wire diameter: 0.9mm *3
0.85MH~1.0MH Wire diameter: 1.0mm * 2
1.2MH ~ 1.6MH Wire diameter: 1.40mm
2.0MH ~ 2.6MH Wire diameter: 1.25mm
3.0MH ~ 3.3MH Wire diameter: 1.10mm
4.0MH ~ 4.5MH Wire diameter: 1.00mm
Using high quality iron silicon aluminum magnetic ring 47X24X18mm permeability: 125
Suitable for sinusoidal inverter filter inductance and PFC inductance: 2000w-3000w range of
power.
