2025 Hot Sales Servo Motor 400w 750w High Speed 3000RPM Servo Motor Kit Support 5V 24V Pulse Signal Analog 0-10V RS485 Modbus
$761.72
Sale price
$761.72
Regular price
$0.00
Description
SPECIFICATIONS
400W: 1.3Nm
750w: 2.4Nm
AC Voltage: 220v
Brand Name: NONE
Cables: 3meters
Certification: CCC,CE,CCC
Does it include a Battery?: No
Does it include wireless functionality?: No
EU LVD Voltage: Low voltage: Below 50Vac or 75Vdc
Efficiency: IE 3
Frequency: 50/60HZ
High-concerned chemical: none
Model Number: HTNC-C30S-400W
Origin: Mainland China
Output Voltage: 400W
Phase: Single-phase
Protect Feature: Totally Enclosed
Support: 5V 24V Pulse Signal Analog -10-10V RS485 Modbus
Type: Servo Motor
motor shaft 400w: 14mm
motor shaft 750w: 19mm
product name: servo motor 400w 750w
speed: 3000RPM
voltage: 200-240v
https://www.youtube.com/watch?v=Yf99H8xPOcw Teach how to use Servo motor
software https://drive.google.com/drive/folders/1WmNfl8vkUXNUk26Uiyw9jn5W8Z54b9gD?usp=drive_link
1: Supports pulse (5V or 24V pulse signal), analog (0-10V), Modbus RS485 control
2: Support CNC and PLC systems
3: To connect 24V pulse signals, P+and D+need to be connected in series with two 2K 1/4W resistors, otherwise the driver will burn out
4: Power on settings
Change P-036 to 1 (reverse direction) and 0 (forward direction) motor direction conversion parameters
Change P-098 to 1 (internal enable) and 0 (external enable)
The larger the P-029 electronic gear ratio parameter, the faster the speed
Press and hold the confirm button on E-SEF to display DONE saved successfully. After setting all parameters, power off and restart.
5：No A B feedback
6400w can replace 4.5Nm stepper motor, 750w can replace 8.5Nm stepper motor
