SPECIFICATIONS

Application: Computer

Brand Name: Gaqqee

Choice: yes

Condition: New

Dissipation Power: low power consumption

High-concerned chemical: none

Operating Temperature: Details Page

Origin: Mainland China

Package: TQFP

Quantity: 1

Supply Voltage: Details Page

Type: Module

is_customized: Yes

Product Features:

1. Manufactured from premium materials, ensuring quality assurance

2. Compact and aesthetically refined design

3. User-friendly operation

4. Stable performance

5. Versatile application scope

Usage:

Single-channel 220V AC optocoupler detection module

Function: Detects presence of 220V AC power

Outputs TTL logic levels for microcontroller detection. Power supply: 3-5V

Alternatively, connect to PLC 24V level.

When interfacing with PLC input:

- Connect PLC's COM terminal to 24V power supply

- Connect PLC input terminal to module's Signal Output (OUT)

- Connect module's GND terminal to power supply negative terminal

- Connect blue 2P 5.0 terminal to 220V voltage

- Connect 3P terminal to microcontroller input

Safety Warning:

When in use, do not touch any components within the white-lined area on the board after powering on this module, as high voltage is present. Exercise caution regarding electrical safety!

Package Contents:

Module ×1
