3-24V 8 Bit Blue/Red Common anode/cathode LED indicator Module Breadboard starter kit Board for MCU ARM 3d printer UNO MEGA2560
3-24V 8 Bit Blue/Red Common anode/cathode LED indicator Module Breadboard starter kit Board for MCU ARM 3d printer UNO MEGA2560
$61.56
Sale price  $61.56 Regular price  $0.00
Color
Description

SPECIFICATIONS

Application: Computer

Brand Name: LAUBEI

Choice: yes

Condition: New

Dissipation Power: w

High-concerned chemical: none

Origin: Mainland China

Package: SMD

Supply Voltage: 3-24v

Type: Voltage Regulator

is_customized: Yes

Product Name: 3.3V 5V 8-bit blue/Red common anode/cathode LED Indicator module diy kit for Arduiuo NANO UNO Raspberry PI 4 nodemcu

Packing list: 1 DC 3-24V 8-bit blue/red common anode/cathode LED lamp strip;

Description: Can be inserted directly into the breadboard, Perfect for connecting your Arduiuo UNO Mini Nano Mega2560 DUE bread board etc or other MCU (AVR STM32 ARM7 ARM9 ARM10 ARM11 PIC C8051 STC MSP430 FPGA/CPLD Etc.)

DC 3.3V 3.7V 5V 12V 24V 8-bit blue/red common anode/cathode LED bar

  • Product Name: 8-Bit LED Bar Graph Module

  • Description: This module consists of eight individual LED bars, each with its own common cathode and anode. The LEDs can be controlled individually to create a variety of visual effects.

  • Specifications:
    • Input voltage: 3.3V - 5V

    • Current consumption: up to 20mA per LED

    • Dimensions: 30mm x 20mm

    • Interface: solder pads for direct connection to a microcontroller or other circuitry

  • Applications:
    • Displaying numerical data such as sensor readings or battery levels

    • Creating simple animations or visual effects

    • Indicating the status of a system or device

  • Usage Notes:
    • Each LED bar has two pins: one for the common cathode and one for the anode. To turn on an LED, connect the cathode pin to ground and the anode pin to a positive voltage.

    • The current through each LED can be adjusted by adding a resistor in series with the anode pin.

    • The module can be powered directly from a microcontroller's digital output pins, but care should be taken not to exceed the maximum current rating of the pins.


Here is a brief description of how to wire the 8-bit LED bar graph module:

      1. Connect the negative terminal of your power source to the common cathode pin of the module.

      2. For each individual LED, connect the positive terminal of your power source through an appropriate resistor to the corresponding positive pin.

      Remember to ensure that your power supply voltage does not exceed the maximum rated voltage for the LEDs, and use proper current-limiting resistors to prevent damage to the LEDs due to excessive current flow.
