30W Pixel OV7670 Camera module, Send Super High Quality Row Seat (30W pixel)
$13.64
Sale price
$13.64
Regular price
$0.00
Description
SPECIFICATIONS
Application: PCB BOARD
Brand Name: FENGZHOUYONGHENG
Choice: yes
Condition: New
Dissipation Power: dsffdsgdf
High-concerned chemical: none
Operating Temperature: xczxvxc
Origin: Mainland China
Package: ffffd
Supply Voltage: sdfgsd
Type: electronics
is_customized: Yes
semi_Choice: yes
Data download:http://pan.baidu.com/s/1c06hYfu
Sensitive array 640 x480
IO voltage of 2.5 V to 3.0 V (internal "to nuclear power 1.8 V)
Power dissipation work 60 mw / 15 fpsvgayuv
Dormancy
Operating temperature - 30 ℃ to 70 ℃
Stable work 0 ℃ to 50 ℃
The output format (8 bits)?YUV/YCbCr4:2-2 RGB565/555/444 GRB4:2-2 Raw RGB Data
Optical size 1/6"
The view Angle of 67 °
Fiona rate 30 FPS VGA
The sensitivity of 1.3 V/(Lux - SEC)
46 the dB SNR
The dynamic range of 52 dB
Browse mode line by line
Electronic exposure lines 1 through 510
Pixel area of 3.6 mu m x 3.6 microns
Dark current 12 mV/s at 60 ℃
