5pcs LCD2004+I2C LCD Display 2004 20x4 2004A Blue Screen HD44780 LCD With IIC/I2C Serial Interface Adapter Module For arduino
Green
$96.30
Sale price
$96.30
Regular price
$0.00
Skip to product information
5pcs LCD2004+I2C LCD Display 2004 20x4 2004A Blue Screen HD44780 LCD With IIC/I2C Serial Interface Adapter Module For arduino
$96.30
Sale price
$96.30
Regular price
$0.00
Description
SPECIFICATIONS
Brand Name: NONE
Display Mode: Standard
High-concerned chemical: none
Model Number: LCD2004+I2C 2004 20x4 2004A Blue/Green screen
Origin: Mainland China
Resolution: 128*160
Type: TFT
is_customized: Yes
5pcs LCD2004+I2C LCD Display 2004 20x4 2004A Blue Screen HD44780 LCD With IIC/I2C Serial Interface Adapter Module For arduino
Introduction
LCD2004 display is a dot matrix module designed to display 20 characters including letter, number, and symbol, supporting 4-bit and 8-bit data transmission mode. It’s quite convenient for beginners to call the built-in library Liquid Crystal compatible with Arduino IDE, no need to edit yourself.
Working voltage: 5V; Contrast adjustable with a 50K potentiometer onside. To use the 3.3V backlight, just connect pin A to 3.3V, pin K to GND.
Note: Solder the pin headers on it before using.
Pins’ Function
VSS: Connected to ground
VDD: Connected to a +5V power supply
VO: To adjust the contrast
RS: A register select pin that controls where in the LCD’s memory you are writing data to. You can select either the data register, which holds what goes on the screen, or an instruction register, which is where the LCD’s controller looks for instructions on what to do next.
R/W: A Read/Write pin to select between reading and writing mode
E: An enabling pin that, when low-level energy is supplied, causes the LDC module to execute relevant instructions.
D0-D7: To read and write data
A and K: Pins that control the LCD backlight
For more details, please click: http://wiki.sunfounder.cc/index.php?title=LCD2004_Module
LCD2004 display is a dot matrix module designed to display 20 characters including letter, number, and symbol, supporting 4-bit and 8-bit data transmission mode. It’s quite convenient for beginners to call the built-in library Liquid Crystal compatible with Arduino IDE, no need to edit yourself.
Working voltage: 5V; Contrast adjustable with a 50K potentiometer onside. To use the 3.3V backlight, just connect pin A to 3.3V, pin K to GND.
Note: Solder the pin headers on it before using.
Pins’ Function
VSS: Connected to ground
VDD: Connected to a +5V power supply
VO: To adjust the contrast
RS: A register select pin that controls where in the LCD’s memory you are writing data to. You can select either the data register, which holds what goes on the screen, or an instruction register, which is where the LCD’s controller looks for instructions on what to do next.
R/W: A Read/Write pin to select between reading and writing mode
E: An enabling pin that, when low-level energy is supplied, causes the LDC module to execute relevant instructions.
D0-D7: To read and write data
A and K: Pins that control the LCD backlight
For more details, please click: http://wiki.sunfounder.cc/index.php?title=LCD2004_Module
