5Sets EL4.5 4.5mm Pitch Automotive Connector Small Tamiya Style 2/3/4/6/9Pin Male Female Plug With Crimp Terminals
4P
$19.85
Sale price
$19.85
Regular price
$0.00
Skip to product information
5Sets EL4.5 4.5mm Pitch Automotive Connector Small Tamiya Style 2/3/4/6/9Pin Male Female Plug With Crimp Terminals
$19.85
Sale price
$19.85
Regular price
$0.00
Description
SPECIFICATIONS
Application: Car Motorcycle Electrical Wiring, Small Tamiya Style Connection
Brand Name: NONE
Certification: CE
Choice: yes
Does it include a Battery?: No
Does it include wireless functionality?: No
EU LVD Voltage: Low voltage: Below 50Vac or 75Vdc
Gender: Male + Female Connector
High-concerned chemical: None
Material: Plastic Shell + Copper Terminals
Model Number: EL4.5 4.5mm Automotive Small Tamiya Connector Kit
Origin: Mainland China
Pin Specification: 2P / 3P / 4P / 6P / 9P
Pitch: 4.5mm
Series: EL Series
Type: Automotive Wiring Connector
Voltage: None
5Sets EL4.5 4.5mm Pitch Automotive Connector Small Tamiya Style 2/3/4/6/9Pin Male Female Plug With Crimp Terminals
Product Description (EL) Strip type connector
Spacing: 4.5 mm
Applicable wire gauge: AWG# 28 ~ # 18
The range of the PCB thickness: 1.6-2.0 mm
Temperature range:-25 C ~ 85 C
Rated voltage: 300 V AC/DC
Rated current: 10-6A
Contact resistance: 0.015 Ω or less
Insulation resistance: 1000 mΩ or higher
The pressure value: 1500V AC/min
Material: Plug: nylon (PA66) UL94V - 2 (0)
Socket: nylon (PA66) UL94V - 2 (0)
Terminals: phosphor bronze
