SPECIFICATIONS

Brand Name: NONE

Condition: New

High-concerned chemical: none

Origin: Mainland China

Type: Switch

1. Output indicator: Green

2. No-load power: <0.05W

3. Full-load power: <4W

4. Operating temperature: -20~70°C

5. Test resistance: 12 ohms at 40V (for 12V)

6. Output power: 3.5W, efficiency approximately 80%

7. Input voltage range: AC50V-277V, DC70V-390V

8. Output current: 12mA-300mA, enters constant current mode at full load

9. Output protection: Overvoltage, overcurrent, overheating, short circuit protection, etc.

10. Output characteristics: Multiple voltage modules can be paralleled to meet the requirements of both small and large currents

11. Output voltage: 12V-0.05V+0.3V (no-load and full-load); -0.1V at light load; rebound at heavy load; ripple of 100mV at 50% load

12. Capacitor temperature rating: 10,000 hours at 105°C; over 5 years at 70°C; approximately 20-50 years at room temperature (not recommended for use above 70°C).
