SPECIFICATIONS

Brand Name: cnlinko

Certification: CE,RoHS,UL,weee

Diameter Range(2pin): 5.0mm

Diameter Range(3pin): 5.2mm

Diameter Range(4pin): 5.3mm

Does it include a Battery?: No

Does it include wireless functionality?: No

EU LVD Voltage: High voltage: Above 50Vac or 75Vdc

High-concerned chemical: none

Model Number: LP-12 Cable Assembly

Origin: Mainland China

Voltage: none

Wire Guage: 0.34-0.5mm²/22-20AWG

Features:

1. Superior IP68 Waterproof Cable Protection – The pre-assembled cable is fully sealed with high-grade silicone, providing IP68 protection against continuous water immersion and resistance against high‑temperature, high‑pressure water jets. This ensures stable signal and power transmission even in rainstorms, marine environments, and high‑pressure washdowns.

2. Optimized 22‑20 AWG Conductor for Stable Power Delivery – Featuring 0.34‑0.5mm² (22‑20 AWG) tinned copper conductors, this cable ensures low resistance and consistent 5A/125V power transmission. The precision‑stranded design minimizes voltage drop over longer runs, delivering reliable performance for sensors, LED lighting, and industrial controls.

3. Flexible 1.03‑5.03 Meter Length Options for Versatile Installation – Available in 1.03m, 3.03m, and 5.03m pre‑terminated lengths, this cable assembly eliminates field cutting and splicing-. Choose the exact length for your application—reducing cable clutter, simplifying inventory management, and ensuring a clean, professional installation every time.

4. Durable PBT Jacket with Exceptional Environmental Resistance – The cable's PBT outer jacket offers UL94 V‑0 flame retardancy, excellent chemical resistance, and UV stability-. It withstands extreme temperatures from ‑25°C to +85°C, resists salt spray corrosion, and protects internal conductors from abrasion, oil, and industrial solvents in demanding outdoor and factory environments-.

5. Pre‑Terminated Design for Plug‑and‑Play Efficiency – Factory‑terminated with gold‑plated contacts, this cable assembly arrives ready for immediate installation-. No soldering, crimping, or specialized tools are required—simply plug and secure. This reduces installation time, eliminates wiring errors, and ensures consistent electrical performance straight out of the box.
