Description

SPECIFICATIONS

Assembly Cable: Soldering

Brand Name: cnlinko

Cable O.D Range: 4.5-5.5mm

Certification: CE,RoHS,UL,weee

Contact resistance: ≤5.0mΩ

Does it include a Battery?: No

Does it include wireless functionality?: No

EU LVD Voltage: High voltage: Above 50Vac or 75Vdc

Flammability rating: UL94-V0

High-concerned chemical: none

Insulation Resistance: ≥500MΩ

Mechanical Life: ≥2000 Cycles

Model Number: LP-12 Semi-metal Four-hole Socket Connector

Operating Temperature: -25℃~+85℃

Origin: Mainland China

Protection Level: IP68(2m/48h)

Rated Currect(2~6pin): 5A

Rated Currect(7~8pin): 3A

Rated Voltage(2~6pin): 125V AC

Rated Voltage(7~8pin): 100V AC

Salt Spray: ≥72H

Shell & insulated parts: Zinc alloy/PBT

Voltage: 自定义编辑

Waterproof cover: Silica gel

Wire Guage(2~6pin): 0.34~0.5mm²/22~20AWG

Wire Guage(7~8pin): 0.25~0.34mm²/24~22AWG

Withstanding Voltage(7~8pin): 1000V AC

Withstanding voltage(2~6pin): 1500V AC

电压: 1V 2V 4V 5V 12V 12V 等或自定义

CNLINKO M12 2 Pin~8 Pin IP68 Waterproof Connector Circular Electrical Plug Panel Socket for LED Screen Industrial Machinery

Features:

IP68 Waterproof & Dustproof – Fully submersible up to 2 meter for 48 hours, protecting against rain, splashing, and even pressure washing. Perfect for outdoor LED screens, marine equipment, and harsh industrial environments where moisture is a constant threat.
2-Pin to 8-Pin Configurations – Available in 2, 3, 4, 5, 6, 7, or 8 pins to handle power, signal, or both in one connector. Use 2-pin for LED power, 4-pin for sensors, or 8-pin for complex industrial controls – one series covers all needs.
Solder-Type Termination for Reliable Custom Cabling – Features solder cup contacts instead of screw terminals, allowing permanent, low-resistance wire attachment. Ideal for custom cable assemblies where vibration can loosen screw connections. Gold-plated contacts ensure ≤5mΩ contact resistance and withstand harsh industrial use.
Gold-Plated Contacts for Long Life – High-quality brass contacts with 3–4µ gold plating provide ultra-low resistance (≤5mΩ) and resist corrosion. Rated for 2000+ mating cycles and 48-hour salt spray test, so they last for years in demanding conditions.
Wide Temperature & Flame-Retardant Body – PBT plastic housing rated UL94 V-0 (flame retardant) and operates from -25°C to +85°C for metal version. Resists UV, oil, acid, and alkali – built tough for outdoor machinery, solar systems, and factory automation.
