Product Manual (Dual SKU: 75T Ice Shield MAKCU BAAN DP + HDMI Version)

Part 1: 75T Ice Shield MAKCU BAAN DP Version (DP Output)

🔍 1. Product Overview

📋 2. Core Parameters

2.1 Core Selling Points

• ✅ 6th Gen DP Enhanced: 2K144Hz/1K240Hz high refresh rate output
• ✅ Customizable Resolution & EDID Adaptive (auto-read monitor model)
• ✅ Dual HDMI Input & seamless switching (no flicker/black screen)
• ✅ One-click fusion & adjustable perspective
• ✅ Low power, zero noise (no cooling fan)
• ✅ Multi-device compatible (desktop/laptop)

2.2 Key Parameters

• Input: 2×HDMI 2.0 (H1=host, H2=auxiliary)
• Output: 1×DP (supports 2K144Hz/1K240Hz)
• Power: DC12V
• Size: 130*90*35mm | Gross Weight: 1Kg/pcs

⚙️ 3. User Guide

3.1 Indicator & Buttons

• D1 (Power): Steady on when powered on
• D2 (Fusion): Steady on when fusion is enabled
• H1/H2: Lights up when receiving signal
• Power Key: On/off; Long press to restart
• K1: Auxiliary device single-screen | K2: Host single-screen
• K3: Fusion on/off; Short press to adjust perspective
• K4: Switch encoding format (for old monitors)

3.2 Basic Connection

1. Connect HDMI cables to H1/H2 and host/auxiliary device graphics cards
2. Connect DP cable to device DP Output and monitor DP port
3. Plug in 12V power adapter, press Power Key to start
4. Use K1-K4 to adjust mode and fusion effect

3.3 Troubleshooting

• ❌ Only D1 on: Check HDMI connection, restart device/computer
• ❌ Flickering/garbled screen: Reduce refresh rate to 60Hz, check cable
• ❌ No fusion: Ensure D2 is on, set auxiliary device background to pure black

Part 2: 75T Ice Shield MAKCU BAAN HDMI Version (HDMI Output)

🔍 1. Product Overview

📋 2. Core Parameters

2.1 Core Selling Points

• ✅ 6th Gen HDMI Enhanced: 2K144Hz/1K240Hz high refresh rate
• ✅ Same fusion/switching function as DP version
• ✅ EDID adaptive & multi-device compatible
• ✅ Low power, zero noise (no cooling fan)

2.2 Key Parameters

• Input: 2×HDMI 2.0 (H1=host, H2=auxiliary)
• Output: 1×HDMI (supports 2K144Hz/1K240Hz)
• Power/Size/Weight: Same as DP version

⚙️ 3. User Guide

3.1 Basic Connection

1. Connect 3 HDMI cables to H1/H2, host/auxiliary device and monitor
2. Plug in 12V power adapter, press Power Key to start
3. Adjust mode and fusion effect as needed

3.2 Package List

• 📦 1× HDMI Device | 1× 12V Adapter | 3× HDMI Cables | 1× Manual & Warranty Card

⚠️ 4. General Notes

• Use only the supporting 12V power adapter
• Keep away from water, humid environments and severe collision
• Disconnect power when not in use for a long time
• Do not disassemble by yourself; contact after-sales for maintenance
• 75T customization available, contact after-sales for support
