SPECIFICATIONS

Brand Name: AOKIN

Choice: yes

High-concerned chemical: none

Model Number: DC 12V 24V to 5V 3A Converter DC Voltage Reducer Regulator

Origin: Mainland China

Output Current: 3A

Output Type: SINGLE

Type: DC/DC Converters

• Input Voltage:DC 12V/24V nominal; Voltage Range: 10-30V; Output Voltage: DC 5V 3A 15W; Maximum Efficiency:≥95%; Ripple Wave: 50Mv; Starting delay time:≤2s.

• Protection: Built in over-load, over-current, over-temperature and short-circuit protection.

• Design: Plastic shell with epoxy potting, anti-dust, anti-shock protection and better heat dissipation.

• Application: Widely used in automotive, surveillance systems, railway signals, medical equipment, instruments, LED strips, cable TV and other low power test systems

• Guarantee:These voltage converters are excellent power transformers, can work safely and reliable in -40°C~80°C range. And all converters are offered 1 year replacement assurance.
