DC 5V-10V PCM5102 DAC Decoder I2S Player Assembled Board 32Bit 384K Beyond ES9023 PCM1794 For Raspberry Pi Arduino
Default Title
$35.15
Sale price
$35.15
Regular price
$0.00
Skip to product information
Power supply:DC 5V-10V
support I2S/left-justified signel directly input (can switch by hand)
The maximum support 32 Bit 384K Sampling rate!
Can setting two FLT filter mode (NOM normal mode or LOW Delay mode)-Need switch by hand!
SNR :112db
Distortion:-93db
Directly output is 2.1V RMS audio voltage ,High frequency is pure ,Low frequency is satiation ,Beyond ES9023
Note:BCK and DATA marked inverse!When using pls make BCK as DATA , DATA as BCK
ASSEMBLED PCM5102 DAC decoder I2S player 32bit 384K beyond es9023
1 x Assembled PCM5102 DAC decoder
DC 5V-10V PCM5102 DAC Decoder I2S Player Assembled Board 32Bit 384K Beyond ES9023 PCM1794 For Raspberry Pi Arduino
$35.15
Sale price
$35.15
Regular price
$0.00
Description
SPECIFICATIONS
Brand Name: NONE
Choice: yes
Compatible Devices Brand: Other
Function: Other
Item Type: MP3 Players Accessories Kits
Origin: Mainland China
semi_Choice: yes
PCB SIZE:4.8x4.8cm
Power supply:DC 5V-10V
support I2S/left-justified signel directly input (can switch by hand)
The maximum support 32 Bit 384K Sampling rate!
Can setting two FLT filter mode (NOM normal mode or LOW Delay mode)-Need switch by hand!
SNR :112db
Distortion:-93db
Directly output is 2.1V RMS audio voltage ,High frequency is pure ,Low frequency is satiation ,Beyond ES9023
Note:BCK and DATA marked inverse!When using pls make BCK as DATA , DATA as BCK
ASSEMBLED PCM5102 DAC decoder I2S player 32bit 384K beyond es9023
1 x Assembled PCM5102 DAC decoder
