SPECIFICATIONS

Brand Name: NONE

Choice: yes

Does it include a Battery?: No

Does it include wireless functionality?: No

EU LVD Voltage: Low voltage: Below 50Vac or 75Vdc

High-concerned chemical: none

Origin: Mainland China

Voltage: 48V

semi_Choice: yes

1, Simple Power up 2 Passive 10/100Mbps PoE devices by one power source Application use for Access Points, IP cameras, IP phones, etc.
2, Power Input terminal block for all PoE power supply, each port serial a recoverable fuse(fuse value 1.1Amp / 72V). Power Expansion Output terminal block can connect power supply to next device.
3, Switch On/Off to save electricity while not use, LED indication for switch On/Off status.
4, Specifications: Terminal Block Power Input: 12VDC - 60VDC, maximum current 10Amp; Termianl Block Expansion Output: maximum current 10Amp; LIN-X Input: RJ45 1 / 2 / 3 / 6 pins(data), 4 / 5 / 7 / 8 pins not connected; PoE-X Output: RJ45 1 / 2 / 3 / 6 pins(data). 4 / 5 pins power +, 7 / 8 pins power -; Data Rate: 10 / 100Mbps; PoE Power Output Maximum Current(per channel): 720mA.

Specifications:
Terminal Block Power Input: 12VDC - 60VDC, maximum current 10Amp.
Termianl Block Expansion Output: maximum current 10Amp.
LIN-X Input: RJ45 1 / 2 / 3 / 6 pins(data), 4 / 5 / 7 / 8 pins not connected.
PoE-X Output: RJ45 1 / 2 / 3 / 6 pins(data). 4 / 5 pins power +, 7 / 8 pins power -.
Data Rate: 10 / 100Mbps.
PoE Power Output Maximum Current(per channel): 720mA.
Terminal blocks: Pitch 5.0mm/0.197", Wire range 28AWG ~ 12AWG / 2.5mm square, Strip length 7mm. Screws - M2.5,steel,Cr3+ Zn plated. Pin header and Cage - Brass.
