Description
SPECIFICATIONS
Application: Computer
Brand Name: Estardyn
Choice: yes
Condition: New
Dissipation Power: 1
High-concerned chemical: none
Operating Temperature: -45-+85
Origin: Mainland China
Package: DIP
Supply Voltage: 4.5-50V
Type: Voltage Regulator
is_customized: Yes
It's LM2596HVS Not LM2596S Chip,please know it
- Type /name:LM2596HVS DC-DC step-down module
- Input Voltage:4.5V ~ 50V
- Output Voltage:3V ~ 40V
- Output Current:3A (max)
- Conversion efficiency:92%(the highest)
- Output Ripple:<30mV
- Switching frequency:150KHz
- Operating Temperature:-45 ° ~ +85 °
- Size:43mm * 21mm * 14mm (L * W* H)
IN-IN + inputPositiveInput Negative!
Positive outputOUT +OUT-output negative
Input voltage range: DC4.5V to53V (inputvoltagemust be greater thanthe outputvoltageto1.5Vor morehigh.Could notboost)
Output voltage range: DC3Vto 40Vvoltage is continuously adjustable, high efficiency(up to 92%)the maximum outputcurrent of3A.
Measured12V input, 5Voutputcurrent is 1Aload regulationrate of less than1%
Note: This is thestep-down module, the input voltagemust behigher than the outputvoltage.
Outputcurrent is greater than2.5A (or outputpower greater than10W)to work long hours, please addheat sink.
