SPECIFICATIONS

Application: Module

Brand Name: GHPYQKC

Choice: yes

Condition: New

Dissipation Power: Module

High-concerned chemical: none

Operating Temperature: Module

Origin: Mainland China

Package: Module

Supply Voltage: Module

Type: Module

is_customized: Yes

semi_Choice: yes

Core Specifications

Model: MCP2551

Standard: ISO 11898-2 High-Speed CAN

Baud Rate: Max 1 Mbps

Supply Voltage: 2.7V ~ 5.5V

Differential Bus Output: CANH / CANL differential signal

Bus Load Capacity: Up to 112 nodes on one bus

Protection Functions: Thermal shutdown, short-circuit protection, reverse voltage protection, ESD protection

Package: DIP-8 through-hole / SOIC-8 SMD

Operating Temperature: -40℃ ~ +125℃ (automotive grade temperature range)

Standby Mode: Low power silent mode to reduce power consumption

Core Features

Strictly follows ISO 11898 CAN bus standard, communication stable and reliable

Supports up to 1Mbps high-speed data transmission, long-distance communication

Multi-layer hardware protection: overheat auto shut down, CANH/CANL short circuit protection, anti-reverse power, anti-static surge

Low standby current, ideal for battery-powered monitoring devices

Compatible with mainstream CAN controllers such as MCP2515, STM32 built-in CAN

Two packages optional: DIP8 for breadboard experiment, SOIC8 for mass production PCB

Wide temperature range from -40℃ to 125℃, adapt vehicle and industrial harsh environment

Application Scenarios

Automotive electronic equipment: car instrument, body control module, new energy vehicle battery management

Industrial field bus: PLC communication, industrial sensor data collection

Robot and automation equipment: multi-axis servo synchronous control

Smart agriculture, environmental monitoring multi-node wired communication

Student electronic experiment, CAN bus development learning board
