Hybrid Easy Servo Nema 34 Stepper Motor Kit With Encoder Driver HSS86 Closed Loop CNC Kit

Hybrid Easy Servo Nema 34 Stepper Motor Kit With Encoder Driver HSS86 Closed Loop CNC Kit

$753.56

$753.56 $0.00

Description

SPECIFICATIONS

Brand Name: XMSJ,JSS MOTOR

Certification: NONE

Current: 6A

Current / Phase: 6A

Encoder Resolution(PPR): 1000

Frame Size: 86*86mm

High-concerned chemical: none

Insulation(mH±20%): 5.2

Model Number: 86HSE12N-BC38

Nema Frame Size: NEMA 34

Origin: Mainland China

Phase: 2, 2

Place of Origin: Jiangsu, China

Resistance(Ω±10%): 0.45

Shaft Diameter: 14mm

Step Angle: 1.8 degree

Torque: 12nm

Type: Hybrid, Hybrid

Voltage: other

Warranty: 3 months ~ 1 year

Please pay attention!! Hello, dear customer. Please consult customer servifor the latest shipping and product prices before placing an order. Prices may depending on your needs. If you directly place an order, it will not be shto you by default.

We have strong technical strength, mature production technology, complete inspection equipment, and excellent quality assurance system and service system. It can provide personalized customization services and industry solutions according to different customer needs, and accept ODM and OEM.

Hybrid Closed Loop NEMA 34 Stepper Motor Kit

*lf you need other stepper motor, please send inquiry to us or contact us directly.

nema 34 stepper motor specifications

Model No.	Step Angle	Current (A)	Resistance (Ω±10%)	Inductance (mH±20%)	Holding Torque (N.m)	Motor Length (mm)	Encoder Resolution (PPR)
86HSE4N-BC38	1.8°	6	0.45	3.7	4.5	82	1000
86HSE8N-BC38	1.8°	6	0.44	3.7	8	118	1000
86HSE12N-BC38	1.8°	6	0.45	5.2	12	156	1000

HSS86 stepper motor driver specifications

Voltage range	AC20~80V or DC30~110V
Peak current	Peak 8.0A（current change according to load）
Logic input current	7~20mA
Frequency	0~200KHz
Suitable stepper motor	2-phase nema 34 hybrid closed loop stepper motor
Encoder lines	1000
Insulation resistance	≥500MΩ

Product Paramenters

About Us

Company Profile

1.Q:Can I get some samples?
A:We are honored to offer you samples for quality check.
2.Q:Do you have the products in stock?
A:Our products are manufactured according to your order except the normal products.
3.Q:What's the delivery time?
A:It usually takes about 7 working days,but the exact delivery time might be different for different order or at different time.
4.Q: How does your factory do regarding quality control?
A: Quality is priority. We always attach great importance to quality control from the beginning to the end of the production.
Every product will be fully assembled and carefully tested before packed.
5. Q:What's your warranty terms?
A: We offer different warranty terms for different products. Please contact with us for details.
