LED Backlight 1210 3528 2835 1W 6V 96LM Cool white LCD Backlight for TV TV Application 01.JT.2835BPWS2-C 500PCS
$50.99
Sale price
$50.99
Regular price
$0.00
Description
SPECIFICATIONS
Brand Name: MUXINZILIGHT
Current: 180MA
High-concerned chemical: none
Item Type: Ball
Model Number: 01.JT.2835BPWS2-C
Origin: Mainland China
Voltage: 3V
MODEL NAME : 01.JT.2835BPWS2-C
Mznufacturer : JUFEI
Origin : China
Package Model:Loaded Quantity 3000PCS Per Reel
Forward Current (IF ): 180mA
Pulse Forward Curren t1 (IFp): 500mA
Reverse Current (IR): 1uA
Reverse Voltage (VR): 10V (1uA)
Power Dissipation (PD): 1.2W
Operatin Tgemperature (Topr): -30 - +85 °C
Storage Temperature (Tstg): -40 - +100 °C
Soldering Temperature (Tsld): Reflow Soldering:260 °C
for 10secs
Hand Soldering:350 °C
for 3secs
Junctio Tnemperature (Tj ): 115°C
Forward Voltage (VF): 6.40-6.60V (150mA)
zuminous Flux (LM): 92-96lm (150mA)
Luminous Intensity ( IV ) : cd (150mA)
Wavelength (nm) : -nm mA
CIE : x=0.2666 y=0.2506 (150mA)
Color Correlated Temperature (CCT):
CRI :
Viewing angle : 120°
Lead Frame Type LED Package: 3.5×2.8×0.8mm L×W×H d=mm
