MH-Z16 IR Infrared CO2 NDIR Carbon Dioxide Gas Air Sensor Module Air Quality Detection 0-5000ppm UART PWM MH Z16 MHZ16

MH-Z16 IR Infrared CO2 NDIR Carbon Dioxide Gas Air Sensor Module Air Quality Detection 0-5000ppm UART PWM MH Z16 MHZ16

$179.10

$179.10 $0.00

Description

SPECIFICATIONS

Brand Name: Your Cee

High-concerned chemical: none

Material: Mixture

Origin: Mainland China

Output: Analog Sensor

Theory: Inductance Sensor

Type: Gas Sensor

Use: Gas Sensor

is_customized: Yes

MH-Z16 carbon dioxide gas sensor (hereinafter referred to as the sensor) is a general-purpose, small-scale sensor that uses the principle of non-dispersive infrared (NDIR) to detect CO2 in the air. It has good selectivity, no oxygen dependence, and long life. . Built-in temperature compensation; digital output and waveform output at the same time, easy to use. The infrared sensor is a high-performance sensor made by closely combining mature infrared absorption gas detection technology with precise optical circuit design and sophisticated circuit design.

Features:

1. High sensitivity, high resolution, low power consumption

2. Provide multiple output methods such as UART and PWM waveforms

3. Fast response time

4. Temperature compensation, excellent linear output

5. Excellent stability

6. Long service life

7. Anti-steam dryness

Application:

The infrared sensor can be widely used in agricultural and animal husbandry monitoring equipment, HVAC equipment, indoor air quality monitoring equipment, industrial process and safety protection monitoring equipment, education and teaching equipment, air purification equipment.

Product parameters:

Product model: MH-Z16

Detection gas: carbon dioxide

Working voltage: 4.5～5.5 V DC

Average current: <85 mA

Interface level: 3.3 V

Measuring range: optional in the range of 0～5% Vol

Output signal: UART/PWM

Warm-up time: 3 min

Response time: T90 <30 s

Working temperature: 0～50 ℃

Working humidity: 0～95% RH (non-condensing)
