SPECIFICATIONS

Application: Electric Toy

Brand Name: NONE

Choice: yes

Condition: New

Dissipation Power: 1.5A

High-concerned chemical: none

Operating Temperature: MX1508 Mini Dual Channel

Origin: Mainland China

Package: SOP

Supply Voltage: 2 Way PWM Speed Controller Dual H-Bridge Replace Stepper

Type: Drive IC

is_customized: Yes

p{margin-block-start: 0; margin-block-end: 0}

Mini L298N Dual Channel Motor Driver Module – Dual H-Bridge, 1.5A Continuous, PWM Speed Control, Ideal for Arduino & Raspberry Pi Smart Cars!

Key Features & Benefits：

✅ Dual Channel Independent Control: Drive two DC motors or one bipolar stepper motor simultaneously, perfect for robot cars and multi-motor projects.

✅ Strong 1.5A Drive Capacity: Each channel delivers 1.5A continuous current (2.5A peak), capable of driving most small to medium DC motors.

✅ Precise PWM Speed Control: Use PWM signals on ENA/ENB pins to easily and precisely control motor speed.

✅ Built-in Safety Protections: Features thermal shutdown and flyback diodes to prevent damage from voltage spikes and motor stalls.

✅ Ultra-Compact Design: Only 24.7x21mm size with low power consumption, ideal for space-constrained and battery-powered applications.

✅ Wide Voltage Compatibility: Motor supply (VM) 2V-10V, logic supply (VCC) 1.8V-7V (3.3V/5V compatible).

Product Description：
This mini L298N module packs the functionality of the classic L298N driver into a tiny footprint, serving as the perfect bridge between your microcontroller's logic signals and the higher power needs of motors. Whether you're building obstacle-avoiding robots, line-following cars, or automated projects requiring precise stepper motor control, it provides a reliable and efficient driving solution.

🚨 Critical Usage Notes (READ BEFORE USE)：

Polarity Warning: NEVER reverse the motor power supply (VM) polarity, as this will instantly destroy the module!

Current & Voltage Limits: Do not exceed 2.5A peak current per channel or 10V input voltage to prevent damage.

Heat Management: The chip will get warm under high load; ensure adequate ventilation even with thermal protection.

Wiring Order Suggestion: Connect logic power (VCC) and control signals first, then motor power (VM) and motors.

Enable Pins: If speed control is not needed, jumper ENA and ENB to VCC for full-speed operation.

Specifications：

Driver IC: L298N

Motor Supply Voltage (VM): 2V - 10V DC

Logic Supply Voltage (VCC): 1.8V - 7V (3.3V/5V compatible)

Drive Current: 1.5A per channel (continuous), 2.5A (peak)

Control Signal: TTL compatible

Module Size: 24.7mm × 21mm × 5mm

Operating Temperature: -25°C to +130°C

Package Includes：

1 × Mini L298N Motor Driver Module
