SPECIFICATIONS

Brand Name: hot rc

Choice: yes

For Vehicle Type: Airplanes

Four-wheel Drive Attributes: M8N GPS

High-concerned chemical: none

Material: Metal

Model Number: BFKJ808

Origin: Mainland China

Quantity: 1 pcs

RC Parts & Accs: Radio Systems

Recommend Age: 14+y

Remote Control Peripherals/Devices: M8N GPS

Size: 13cm x 12cm x 12cm

Technical parameters: value 2

Tool Supplies: M8N GPS

Upgrade Parts/Accessories: Frame

Use: Vehicles & Remote Control Toys

Wheelbase: Screws

Receiver type 72-channel M8 engine
GPS/QZSS L1 C/A, GLONASS L10F, BeiDou B1
SBAS L1 C/A: WAAS, EGNOS, MSAS
Galileo-ready E1B/C
Nav. update rate1 Single GNSS: up to 18 HZ
Concurrent GNSS: up to 10 Hz
Position accuracy2 2.0 m CEP
Acquisition2 Cold starts: 26 s
Aided starts: 2 s
Reacquisition: 1.5 s
Sensitivity2 Tracking & Nav: -167 dBm
Cold starts: -148 dBm
Hot starts: -156 dBm
Assistance AssistNow GNSS Online
AssistNow GNSS Offline (up to 35 days)3
AssistNow Autonomous (up to 6 days)
OMA SUPL & 3GPP compliant
Oscillator TCXO
Crystal
RTC crystal Built-In
Noise figure On-chip LNA . Extra LNA for
lowest noise figure
Anti jamming Active CW detection and removal. Extra
onboard SAW band pass filter
Memory ROM or Flash
Supported antennas Active and passive
Odometer Travelled distance
Data-logger For position, velocity, and time
Operating temp. -40° C to 85° C
Storage temp. -40° C to 85° C
-40° C to 105° C
RoHS compliant (lead-free)
Qualification according to ISO 16750
Manufactured and fully tested in ISO/TS 16949 certified production sites
Uses u-blox M8 chips qualified according to AEC-Q100

Supply voltage 1.65 V to 3.6 V
2.7 V to 3.6 V
Power consumption4 23 mA @ 3.0 V (continuous)
5 mA @ 3.0 V Power Save Mode
(1 Hz, GPS mode only)
Backup Supply 1.4 to 3.6 V
M8 Concurrent GNSS LCC Module,
TCXO, flash, SAW, LNA,
Timepulse Configurable 0.25 Hz to 10 MHz
