SPECIFICATIONS

Product Introduction

The product adopts industrial-grade chips and high-precision imported SHT20 temperature and humidity sensors, ensuring excellent reliability, high precision and interchangeability of the product. This product adopts an RS485 hardware interface (with lightning protection design), and the protocol layer is compatible with the standard industrial MODbus-RTU protocol. It integrates the MODBUS protocol and the common protocol. Users can choose the communication protocol by themselves. The common protocol has an automatic upload function (when connected to RS485, the temperature and humidity will be automatically output through the serial port adjustment tool).

Product Features

- RS485 communication

- 35mm standard rail mounting

- High precision and high quality sensors

- SHT20 Modbus protocol and custom common protocols

- Stable and reliable

- Wide voltage power supply

- Low power consumption

- The rail card installation is convenient to use

Product parameters

Product Name: Temperature and Humidity Transmitter

DC Power Supply: DC5-30V

Output Signal: RS485 signal

Communication Protocol: Modbus-RTU protocol and self-defined Common protocol

Communication Address: 1 to 247 can be set, with a default of 1

Baud Rate: Settable. The default is 96,008 bits of data, and it stops at 1 bit

Temperature Accuracy: ±0.5℃(25℃)

Humidity Accuracy: ±3%RH

Temperature Range: -40℃ to +60℃

Humidity Range: 0%RH to 80%RH

Temperature Resolution: 0.1℃

Humidity Resolution: 0.1%RH

Equipment Power Consumption: ≤0.2W
