New 1- 10PCS SMA Male Plug Female Jack /RP RF Coax Connector Crimp For LMR100 RG174 RG316 Cable Straight Goldplated Adapter
RP SMA female / 10PC
$16.92
Sale price
$16.92
Regular price
$0.00
Skip to product information
New 1- 10PCS SMA Male Plug Female Jack /RP RF Coax Connector Crimp For LMR100 RG174 RG316 Cable Straight Goldplated Adapter
$16.92
Sale price
$16.92
Regular price
$0.00
Description
SPECIFICATIONS
Brand Name: DexMRtiC
Cable type: RG316 RG174
Certification: CE
Choice: yes
Does it include a Battery?: No
Does it include wireless functionality?: No
EU LVD Voltage: Low voltage: Below 50Vac or 75Vdc
Gender: RP-SMA male with female pin
High-concerned chemical: none
Impedance: 50Ohm
Material: Brass
Model Number: SMA Male RF connector
Mounting: Cable mount
Origin: Mainland China
Plating: Goldplated
Product Type: SMA coax connector
Style: Straight
Voltage: none
semi_Choice: yes
1pc 2pcs 10pcs SMA male/ female/ RP plug/ jack RF Coax connector crimp for RG316 RG174 cable straight goldplated NEW wholesale
SMA connectorseries product is a widely used small coaxial connectors with threaded connections. The SMA series inch threaded connections, high strength, good shock resistance. The outer conductor ends in direct contact, so that the insertion loss to a minimum.
Applications
1.Antennas
2.Broadcast
3.radios
4.Electronic test equipment
5.Serial digital and Analog interface
6,Non-professional radio antenna connections
50Ω Specifications
Electrical | ||||
Impedance |
50 Ω |
|||
Frequency Range |
0-4 GHz with low reflection |
|||
Voltage Rating |
500 volts peak |
|||
Dielectric Withstanding Voltage |
1,500 volts rms |
|||
VSWR |
M39012 straight connectors: 1.3 max 0-4 GHz M39012 right angle connectors: 1.35 max 0-4 GHz |
|||
MIL-C-39012 Contact Resistance |
Center contact: ≤3mΩ; Outer contact: ≤2mΩ |
|||
MIL-C-39012 Insulation Resistance |
5,000 MΩ |
|||
Durability |
500 Cycles |
|||
APPLICABLE STANDARD |
|
|||
Material | ||||
Contact |
Brass,goldplated |
|||
Insulator |
PTFE |
|||
Crimp Ferrule |
Copper/brass |
|||
Environmental | ||||
Temperature Range |
TFE insulators: - 65°C to + 165 °C Copolymer of Styrene: - 55°C to + 85°C |
|||
Note: These characteristics are typical but may not apply to all connectors.
