SPECIFICATIONS

Brand Name: NONE

Certification: NONE,NONE

Current: /

EU LVD Voltage: Low voltage: Below 50Vac or 75Vdc

Features: /

High-concerned chemical: none

Is Smart Device: no

Item Type: SWITCHES

Material: Plastic

Model Number: Limit Switch ME-8108

Origin: Mainland China

Switch Type: Knob switch

Warranty: -

Description:
1. Limit switch ,compact design,long mechanicatical life.
2. Easy wiring with full open terminals.
3. High precision, high reliability
4. Dust proof ,water proof ,oil proof construction (IP64)
5. Double circuit type.
6. 5A load current
7. Strong body with combination of reinforced plastic and aluminium Die Casting compaonents.
8. Build in basic switch with doule spring mechanism.

Characteristics:
1. Operation speed: 0.5mm-50cm/sec
2. Operating frequency:
Mechanical: 120 operations/minute
Electrical: 30 operations/minute
3. Contact resistance: 25mΩ max. (initial value)
4. Insulation resistance: 100mΩ min. (at 500VDC)
5. Dielectric strength:
1000VAC, 50/60HZ for 1 minute between terminals of the same polarity
1500VAC, 50/60 HZ for 1 minute between currentcarrying and non-current-carrying metal parts
1500VAC, 50/60 HZ for 1 minute between each terminal and ground
6. Vibration: 10-55HZ,1.5mm double amplitude
7. Shock:
Mechanical durable: 1, 000m/Sec2 (about 100GS)
Malfunction: 300m/Sec2 (about 30GS)
8. Ambient temperature: -5°C to +65°C
9. Humidity: <95% RH
10. Life:
Mechanical: 10,000,000 operations above
Electrical: 500,000 operations above
11. Degree of protection: IP65
