SMA RP SMA Male Plug Female RF Coax Connector Crimp for RG174 RG316 RG178 RG179 LMR100 Cable Brass Gold Plated High-quality
Type2 / 20PCS
$66.16
Sale price
$66.16
Regular price
$0.00
Skip to product information
1.Frequency:0~6GHz
2.Impedance 50Ω
3.VSWR: <1.5
4.Working Voltage:335V
5.Withstanding Voltage: 1000V
6.Insulation Resistance: >5000MΩ
7.Contact resistance: Inner conductor <3mΩ Outer conductor <2m2Ω
8. Insertion loss: <0.5dB
9. Unnotched tolerance according to earth 0.2
SMA RP SMA Male Plug Female RF Coax Connector Crimp for RG174 RG316 RG178 RG179 LMR100 Cable Brass Gold Plated High-quality
$66.16
Sale price
$66.16
Regular price
$0.00
Description
SPECIFICATIONS
Brand Name: MEYNOOE
Certification: NONE
Does it include a Battery?: No
High-concerned chemical: none
Model Number: SMA
Origin: Mainland China
Voltage: 24V
SMA RP SMA Male Plug Female RF Coax Connector Crimp for RG174 RG316 RG178 RG179 LMR100 Cable Brass Gold Plated High-quality
Specification:1.Frequency:0~6GHz
2.Impedance 50Ω
3.VSWR: <1.5
4.Working Voltage:335V
5.Withstanding Voltage: 1000V
6.Insulation Resistance: >5000MΩ
7.Contact resistance: Inner conductor <3mΩ Outer conductor <2m2Ω
8. Insertion loss: <0.5dB
9. Unnotched tolerance according to earth 0.2
