Snvi DS1307 PCF8563 RTC Module Real Time Clock I2C Timekeeping Backup Battery with Case Cable

Snvi DS1307 PCF8563 RTC Module Real Time Clock I2C Timekeeping Backup Battery with Case Cable

$16.83

$16.83 $0.00

Description

SPECIFICATIONS

Brand Name: SNVI

Choice: yes

Condition: New

High-concerned chemical: none

Origin: Mainland China

Type: Voltage Regulator

semi_Choice: yes

Product Parameters

Parameters for Unhoused / Housed Versions

(Detailed Introduction)

Product Introduction

This module primarily utilizes the real-time clock chip DS1307. It is an I2C bus interface real-time clock chip launched by Dallas Semiconductor (USA). It can operate independently of the CPU, unaffected by the CPU's main crystal oscillator and its capacitors, and features accurate timing with a monthly cumulative error generally less than 10 seconds.

The chip also has a clock protection circuit for situations where the main power supply fails. The DS1307's clock is maintained by a backup battery, which prevents the CPU from accessing it for reading and writing. Additionally, it has an automatic backup power supply switching control circuit, thus ensuring accurate system clock timing even when the main power supply fails or in other harsh environmental conditions.

Explanation

Core Component: DS1307 real-time clock chip, a widely used RTC chip in electronics due to its reliability and I2C bus compatibility.
Key Features: Independent operation from the CPU, accurate timing with low cumulative error, and backup power protection to maintain timekeeping during main power outages. It is commonly used in Arduino and other microcontroller projects for applications requiring precise time tracking, such as data logging, time-stamped events, and automated systems.
Versions: The module is available in unhoused (bare circuit board) and housed (with a protective casing) options, catering to different needs for durability and integration in projects.

Product Parameters Table

Parameter	Specification
Maximum VCC Voltage	5V
Minimum Power Supply Voltage	4V
Memory Capacity	56 BYTES
Memory Type	RAM
Operating Temperature	0℃～+70℃
Interrupt Type	All-day Time
Interface Type	SERIAL, I2C
Clock Frequency	32.768KHZ
Feature	Square Wave Output
Type	RTC
Surface Mount Device	Through-hole Mount

Explanation

This is a real-time clock (RTC) module, likely based on the DS1307 chip (consistent with prior context). Key features include:

Power & Memory: Operates within 4V-5V, with 56 bytes of RAM for temporary data storage.
Timing & Interface: Uses a 32.768KHZ clock frequency for accurate timekeeping, supports I2C and serial interfaces for easy integration with microcontrollers like Arduino.
Functionality: Offers all-day time interrupts and square wave output, enabling applications like periodic event triggering.
Physical & Environmental: Through-hole mounting for stability, works in 0℃-70℃, suitable for general electronic projects requiring reliable time tracking.
