Split Type Current Transformer 2000:1 1000:1 For Electricity Meters CT KCT16 /mA 50A/25mA 100A/100mA

Split Type Current Transformer 2000:1 1000:1 For Electricity Meters CT KCT16 /mA 50A/25mA 100A/100mA

1000 1 / 20A 3PCS
$101.57
$101.57 $0.00
Skip to product information
Split Type Current Transformer 2000:1 1000:1 For Electricity Meters CT KCT16 /mA 50A/25mA 100A/100mA
  • Split Type Current Transformer 2000:1 1000:1 For Electricity Meters CT KCT16 /mA 50A/25mA 100A/100mA
  • Split Type Current Transformer 2000:1 1000:1 For Electricity Meters CT KCT16 /mA 50A/25mA 100A/100mA
  • Split Type Current Transformer 2000:1 1000:1 For Electricity Meters CT KCT16 /mA 50A/25mA 100A/100mA
  • Split Type Current Transformer 2000:1 1000:1 For Electricity Meters CT KCT16 /mA 50A/25mA 100A/100mA
  • Split Type Current Transformer 2000:1 1000:1 For Electricity Meters CT KCT16 /mA 50A/25mA 100A/100mA
  • Split Type Current Transformer 2000:1 1000:1 For Electricity Meters CT KCT16 /mA 50A/25mA 100A/100mA
  • Split Type Current Transformer 2000:1 1000:1 For Electricity Meters CT KCT16 /mA 50A/25mA 100A/100mA
  • Split Type Current Transformer 2000:1 1000:1 For Electricity Meters CT KCT16 /mA 50A/25mA 100A/100mA
Split Type Current Transformer 2000:1 1000:1 For Electricity Meters CT KCT16 /mA 50A/25mA 100A/100mA
Split Type Current Transformer 2000:1 1000:1 For Electricity Meters CT KCT16 /mA 50A/25mA 100A/100mA
$101.57
$101.57 $0.00
Color
Output Voltage
Description

SPECIFICATIONS

Brand Name: CNYANNUA

Does it include a Battery?: No

Does it include wireless functionality?: No

EU LVD Voltage: Low voltage: Below 50Vac or 75Vdc

High-concerned chemical: none

Model Number: KCT16

Origin: Mainland China

Phase: SINGLE

Use: Current

is_customized: Yes

1000:1

5A/5mA 10A/10mA 20A/20mA 30A/30mA 40A/40mA 50A/50mA 60A/60mA 80A/80mA 100A/100mA




2000:1

5A/2.5mA 10A/5mA 20A/10mA 30A/15mA 40A/20mA 50A/25mA 60A/30mA 80A/40mA 100A/50mA


Specifications

Frequency: 50-2KHz

Rated input: 5A-630A

Measurement range: 10% In -120% In

Rated output: 0.333V (AC) or 0-500mA

Error: ≤ ± 1.0%

Angle difference: ≤ ± 60min

Insulation strength: 2.5KV/1mA/1min

Insulation resistance: DC500V/100MQmin

Shell: PA/UL94-V0

Copper tube material: PBT

Iron core: silicon steel

Internal structure: epoxy

Installation method: buckle

Working temperature: -25C~75C

Working humidity:<85%

Output connection: UI101520AWG standard double lead wire 1 meter



Packaging includes

3PCS × KCT16 CT
