SPECIFICATIONS

Brand Name: NONE

Choice: yes

Model Number: ft232r-ttl-6p

Origin: Mainland China

Package: Yes

Type: Serial Cable

semi_Choice: yes

USB to TTL Serial UART Converter Cable with FTDI Chip Terminated by 6 Way Header, Works with Galileo Gen2 Boards/BeagleBone Black/Minnowboard Max and More

FTDI chip usb to 3.3V 5V TTL UART serial cable

Length: 6ft/1.8Meter

FTDI based USB to TTL Serial Cable are designed using the the standard FT232RL chipset.USB to UART cable with 5V TTL level UART signals.

6 output wires terminated by a 6 way, 0.1”, Single-In-Line (SIL) connector

6 way outputs provide Tx, Rx, RTS#, CTS#, VCC and GND. Data transfer rates from 300 baud to 3 Mbaud at TTL levels

5V VCC,  3.3V I/O AND 5V I/O

TTL-232R-3V3      5V VCC-3.3V I/O (signals only, VCC= +5V)

TTL-232R-5V     5V VCC-5V I/O (signals only, VCC= +5V)

USB TTL Serial cable is a range of USB to TTL serial UART converter cables featuring original and genuine FTDI's FT232RL USB to serial UART interface IC device which handles all the USB signalling and protocols

Provides a fast, simple way to connect devices with a TTL level serial interface to USB. Support EEPROM, Vendor ID re-write, debrick Netgear routers and Mprog3.5; Support FTDI VCP driver and D2XX driver

Provides access to UART Transmit (Tx), Receive (Rx), RTS#, CTS#, VCC (5V) and GND connections. RoHS compliant and CE approved

Replace MAX232 type level shifters allowing for direct connection of products to PC via USB

Operating system Compatibility: Windows 10/8/7, Windows Vista, Windows XP, Windows 98, Windows ME, Linux and Mac OS. Please check for details in 'Product description' by scrolling down this page

The USB side of the cable is USB powered and USB 2.0 full speed compatible, while the other end is a 6 way, 0.1”, Single-In-Line (SIL) pitch connector. The length of the cable is 6ft(1.8m) and UL ‘E326510’ certified

Galileo Gen2 Boards Console Serial Cable

ttl-232r-3v3 ttl-232r-5v  galileo gen2 board program cable

FT232RL USB TTL 3.3v 5V adapter cable

FTDI Cable: USB to Serial , TTL 3.3V/5V Level

USB UART TTL level cable

FTDI FT232RL chip, TTL-232R_RPi kable

Compatible with FTDI TTL-232R-3V3 / 5V

UART TTL 3.3V 5Vlevel signals

Compatible with TTL-232R-3V3

Support VCC/TX/RX/CTS/RTS/GND

Support EEPROM, support Vendor ID re-write,support Mprog3.5

Support FTDI VCP driver and D2XX driver

 USB UART to 0.1"(2.54mm) 1*6p female housing

 Standard pinout: GND (Blk/1), CTS (Brown/2), VCC(red/3), TXD (orange/4), RXD  (yellow/5),RTS (Green/6)

 26AWG*6C+AL, 1.8m, OD=4.5mm, black

 ABS black shell type

 PE bag for each cable, 100% test

Drivers are available which allow FTDI devices to work with the following operating systems:

OS Compatibility Windows 8 / 8.1 (32/64bit), 10 (32/64), Vista (32/64), XP (32/64), 2000, 98SE, XP Embedded, CE (4.2+)

Windows Server 2012, 2008 R2, 2003

Mac OS 10.x (Tested up to 10.9)

Linux 2.4.x / 2.6.x

Windows Server 2008 R2

Windows 7

Windows 7 x64

Windows Server 2008

Windows Server 2008 x64

Windows Vista

Windows Vista x64

Windows Server 2003

Windows Server 2003 x64

Windows XP

Windows XP x64

Windows ME

Windows 98

Linux

Mac OS X

Mac OS 9

Mac OS 8

Windows CE.NET (Version 4.2 and greater) Android

Package :

• 1 x usb ttl uart 6pin cable
