SPECIFICATIONS

Functional characteristics: 1. Enhanced anti-interference, internal digital signal processing, direct high and low level output.
2. Repeatable trigger method: that is, after the sensing output is high, during the delay period, if a human body is active in its sensing range, the output will remain high until the person leaves and it will change to low level.(That is, the sensing module will automatically extend for a delay period after detecting each activity of the human body, and the time of the subsequent activity will be the starting point of the delay time).

Technical parameters:
1. Working voltage: DC2.7- 12V;
2. Static power consumption: <0.1mA;
3. Delay time: 2 seconds;
4. Blocking time: 2 seconds;
5. Trigger method: Repeatable;
6. Sensing range: ≤100 degrees cone angle, 3-5 meters;(Depending on the specific lens)
7. Working temperature: -20℃~+60℃

8.Modular lens: small lens
