3.3V 5V Active Buzzer Module High/Low Trigger Piezo Buzzer Sound Alarm Module Compatible With 3.3V 5V Microcontroller
Low Level Trigger
$10.32
Sale price
$10.32
Regular price
$0.00
Skip to product information
3.3V 5V Active Buzzer Module High/Low Trigger Piezo Buzzer Sound Alarm Module Compatible With 3.3V 5V Microcontroller
$10.32
Sale price
$10.32
Regular price
$0.00
Description
SPECIFICATIONS
Brand Name: NONE
Choice: yes
High-concerned chemical: none
Model Number: Active Buzzer Module
Origin: Mainland China
3.3V-5V Active Buzzer Module | High / Low Level Trigger Optional | Easy Control for All MCU
1. Product Overview
This is a 3-wire active buzzer alarm module, powered by 3.3V-5V wide voltage, compatible with Arduino, STM32, Raspberry Pi, 51 single-chip microcomputer and other mainstream controllers.
Built-in S8050 triode drive circuit, with reserved mounting hole for fixed installation. Two trigger versions available: High Level Trigger & Low Level Trigger, to meet different circuit design demands.
2. Two Types of Active Buzzer Module Parameter
✅ High Level Trigger Buzzer Module
Drive Component: S8050 Transistor
Operating Voltage: 3.3V - 5V DC
PCB Dimension: 32mm × 13mm
Trigger Logic: Buzzer sounds when I/O pin outputs HIGH level
Reserved mounting hole for easy fixing
✅ Low Level Trigger Buzzer Module
Drive Component: S8050 Transistor
Operating Voltage: 3.3V - 5V DC
PCB Dimension: 32mm × 13mm
Trigger Logic: Buzzer sounds when I/O pin outputs LOW level
Reserved mounting hole for easy fixing
