SPECIFICATIONS

Brand Name: jshej

Choice: yes

Model Number: 7225 detector

Origin: Mainland China

semi_Choice: yes

Specification:

working voltage: 7.5-16v

Detection range: 7.6m*7.6m


Power requirements: 25mA / 7.5-16VDC (UL: 8.9-14.5 VDC)


Sensitivity: detection of the normal pace, as the region steps 2-4


Microwave frequency: 24.125GHz


Tamper switch: (NC) 50mA, 24VDC


Alarm Relay: excitation type A 500mA, 30 VDC


Operating temperature: -10 55 , 5% - 95% relative humidity non-condensing


Radiated Immunity: 30V / m, 10MHz - 1000MHz

Anti-white light: 8,000 Lux

Features

Has excellent resistance to false alarms and the ability to capture


Easy and quick installation


Built-in temperature compensation and microwave anti-jamming capabilities to adapt to a variety of hot and cold environments


K-band microwave technology to further suppress false positives, and to improve the detector sensitivity

ABS rugged durability, excellent shock

package:

1* 7225 detector

1* support bracket
