SPECIFICATIONS

Brand Name: NONE

Certification: NONE

Choice: yes

Color: Black

Connectors: DC+BNC+RCA

High-concerned chemical: none

Item Type: Video Converter

Model Number: BNC Video Power Balun

Origin: Mainland China

Plug Type: None

Resolution: 8MP

Size: None

Style: BNC Video Power Balun

Used For: 8MP/5MP/3MP/2MP AHD/CVI/TVI/CVBS Camera

8MP CCTV 3 IN 1 Coax BNC Video Power Balun Transceiver to CAT5e 6 RJ45 DC + BNC + RCA Connector Cables For AHD Camera

Features:

3 IN 1 Balun is Power +Video +Audio Balun:

Easy installation, using thestandard UTP cable system.
Using UTP cable ( CAT5, RJ45) to transmit video, audio signal instead of co-axial.
Support all video device, such as camera, monitor, DVR card and recorder etc.
Image with high quality in long distance.
Built - in transient protection.Excellent anti-jamming ability.
Real-time monochrome or color transmission PAL, NTSC, SECAM and other standard baseband video signal.
Passive UTP video transmission equipment, and can be used for sending and receiving, without providing power.

Specifications:
Size: 43×22×21mm/1.69×0.87×0.83in (Approx.)
Video Format: NTSC / PAL / CCIR / SECAM
- Frequency respond: DC-6MHz
- Common-ode / differential-mode rejection: 15HKz - 6MHz 60dB type
Video In / Out: BNC (Male) x 1 + BNC (Male) x1
Power Input: DC 12V
Frequency Response: DC to 6MHz
Impedance:
- Coaxial cable BNC Male: 75 Ω
- UTP RJ45 Data Connector: 100 Ω
Working temperature: -10 ° to +70 °
Storage temperature: -30 ° to +70 °
Humidity: (non-condensing) 0-95%
Quantity: 1 Set(1 Pair) (other accessories demo in the picture is not included)

Note:
1.Transition: 1cm=10mm=0.39inch
2.Please allow 0-1cm error due to manual measurement. pls make sure you do not mind before you bid.
3.Due to the difference between different monitors, the picture may not reflect the actual color of the item. Thank you!
