DC12V Curtain Window PIR Sensor Alarm Detector with NO/NC Output for All Wired Home Burglar Security Alarm System
5pcs
$434.70
Sale price
$434.70
Regular price
$0.00
Skip to product information
DC12V Curtain Window PIR Sensor Alarm Detector with NO/NC Output for All Wired Home Burglar Security Alarm System
$434.70
Sale price
$434.70
Regular price
$0.00
Description
SPECIFICATIONS
Anti white light: >10000LUX
Brand Name: Emooluxr
Detection Angle: 360 degree
Detection Range: 7m*7m
Dimension: 115mm*32mm
High-concerned chemical: none
MW frequency: 10.525GHz
Model Number: X1520
Operating Voltage: 9-16V/DC
Origin: Mainland China
RFI/EMI Protection: >30V/m
Sensitivity: Low or High
DC12V Curtain Window PIR Sensor Alarm Detector with NO/NC Output for All Wired Home Burglar Security Alarm System
Introduction:
This curtain motion detector with direction-recognition adopts dual-element PIR sensor combined
with advanced soft-processing technology, can recognize intruder's get in and out direction. It uses bi
directional temperature-compensation technology, can make accurate intrusion detection in a wide detection
range. This detector is with super low failed alarm and false alarm rate, at the same time, it is with alarm delay
function for convenient activity in terrace when installed on terrace or windows. In addition, it is also
functioning remarkably in anti fictitious movement from hot-air, window blind swaying etc. This sensor is
elegant in appearance and flowing in lines, can match with modern smart home environment perfectly. Its
installation is very convenient, is suitable for terrace, door and window installation. Its function and stability
exceeds other PIR detector with similar price in the market.
Feature:
- Alarm direction for optional change
- Alarm delay for option
- 4 alarm delay times for option
- Alarm output NO/NC for option
- Bi-directional temperature compensation
- Surface mount installation
- EDS/anti electric shock/anti mobile interference
- Anti white light interference
- Fully-sealed optical parts
- Multiple installation methods for option
Parameter:
Power supply: 9-16VDC
Power consumption: NO output: 4.5mA stand by; 20mA during alarm;
NC output: 9mA stand by; 16mA during alarm
Installation height: 4m max (Ceiling mount)
Installation ways: wall mount/ceiling mount(suggested)
Coverage: 9m×1.2m 10°
Alarm time: 3s
Alarm delay: On/off for option
Delay time: 40s/2min/4 min /10min optional
Alarm direction: can be changed
Anti RFI/EMI: 0.1-500MHz/3V/m
Anti white light: >10000LUX
Alarm output : NO/NC optional
Alarm capacity: 100mA/24V
Tamper capacity: 100mA/24V
Temperature: -20℃/+50℃
Humidity: 95%RH
Detect speed: 0.2m/s to 3.5m/s
Dimensions: 90mm×51mm×38mm
Package Content:
1/5pc Wired Curtain PIR Sensor(Each includes bracket, screws, English manual)
Note: Wired pir sensor can connect to all wired alarm system that has wired ports.
