TB6600 / DM542 / DM556 Nema 23 Stepper Motor Driver with Nema23 Stepper Motor 2N.M 76cm 57hs76 CNC Engraving Milling Machine
$277.36
Sale price
$277.36
Regular price
$0.00
Description
SPECIFICATIONS
Brand Name: HLTNC
Certification: CE
Current / Phase: 3a
DM542: DC 24-60V 4.5A for nema23 setepper motor
DM556: dc 20-50v 5.6a for nema23 setepper motor
Does it include a Battery?: No
Does it include wireless functionality?: No
High-concerned chemical: none
Holding Torque: 2nm
Lead Wire: 4
Lead time: in stock
Model Number: TB6600/DM542/DM556
Motor: Stepper Motor
Motor Type: Stepper Motor
Origin: Mainland China
Package: Original Package
Phase: 2
Power Supply: DC
Shaft Diameter: 8mm
Step Angle(degrees): 1.8
motor Model Number: 57hs76-3004
tb6600: 9V-42V DC 4A for nema17/23 setepper motor
Model No |
Step Angle (°) |
Rated Voltage (V) |
Rated Current (A) |
Phase Resistance (Ω) |
Phase Inductance (mH) |
Holding Torque (Kg.cm) |
Detent Torque (G.cm Max) |
Rotor Inertia (g.cm^2) |
Motor Length (mm) |
Lead Wires No. |
Motor Weight (Kg) |
57hs56-3004 |
1.8 |
2.85 |
3 |
0.95 |
2.8 |
12 |
400 |
300 |
56 |
4 |
0.7 |
57hs76-3004 |
1.8 |
2.7 |
3 |
0.9 |
3.5 |
20 |
680 |
480 |
76 |
4 |
1 |
57hs82-3004 |
1.8 |
3 |
3 |
1.4 |
5 |
22 |
700 |
510 |
82 |
4 |
1.2 |
57hs100-3004 |
1.8 |
3 |
3 |
1 |
4.5 |
25 |
1000 |
680 |
100 |
4 |
1.4 |
57hs112-4004 |
1.8 |
3.6 |
4 |
0.9 |
4 |
30 |
1200 |
800 |
112 |
4 |
1.7 |
57hs112-3004 |
1.8 |
3.9 |
3 |
1.3 |
6.5 |
30 |
1200 |
800 |
112 |
4 |
1.7 |
All the motor have dual shaft version. Click Model to see details.
|
|
1 Pcs Driver (The Model as your choice) |
|||
|
1* Nema23 57x76mm 2Nm Stepper Motor (Single Or Dual Shaft) |
|||
Double means that the motor with dual shaft , both of the two side with shaft,
the motor above is dual shaft motor,handwheelcould be installed on the another shaft.
Single means single shaft motor
🚀 Powerful power, precise handling
2N. M High Holding Torque: Provides sufficient cutting force to easily handle carving and lightweight milling tasks of materials such as wood, acrylic, aluminum, and copper, effectively avoiding step loss and stuttering during the processing.
Low vibration and low noise: The motor runs smoothly with low noise, and can maintain smooth motion even at low speeds, significantly improving the smoothness and accuracy of the machined surface.
🔧 Flexible driving, wealth and frugality are determined by people
Multi drive compatibility: We offer a variety of drive options, including the classic TB6600 (cost-effective choice), the mid to high end DM542 (high-performance mute), and the high-speed and high segmentation DM556. You can freely match them according to your requirements for noise, speed, and accuracy, and find the perfect combination that best suits your budget and needs.
💪 Industrial quality, durable and long-lasting
Standard Nema23 specification (57 series): Adopting a fully metal body (57HS76-XXX), the structure is sturdy and the heat dissipation performance is excellent, ensuring that the motor remains stable and reliable even under long-term high load operation. High quality materials and processes: high-precision bearings and pure copper coils ensure high efficiency, low heat generation, and long service life of the motor.
🛠️ Ready to use, worry free and effortless
Wide compatibility: Perfectly compatible with most DIY CNC engraving machines, laser cutting machines, 3D printers, and automation equipment based on GRBL, Mach3, LinuxCNC and other control systems on the market.
Easy installation: Standard installation holes seamlessly connect with most Nema23 brackets and couplings, making your upgrade or assembly process easy and fast.
|
Hybrid Stepper Motor Type 57HS76 | ||||
|
Specifications |
Diagram |
|||
Step Angle |
1.8°± 5% |
Current |
3.0A |
|
Phase No. |
2 |
Resistance |
1.4±10% Ω |
|
Insulation Resistance |
100Mohm(500V DC) |
Inductance |
3.5±20% mH |
|
Insulation Class |
B |
Holding Torque |
20kg.cm 2Nm) |
|
|
Microstep Dirver DM542 | ||||
Specification | ||||
Name |
DM542 Stepper Motor Driver |
|||
Voltage |
24-50VDC |
|||
Current |
1.0-4.2A |
|||
Microstep |
256 |
|||
Description |
Min |
Suggest |
Max |
|
Supply Voltage VDC (3A) |
24 |
36 |
50 |
|
Output Current(Peak Value) A |
1 |
/ |
4.2 |
|
Logic Control Input Current (mA) |
8 |
10 |
20 |
|
Stepping Impulse Response Frequency(khz) |
0 |
/ |
200 |
|
Cooling |
Natural Cooling |
|||
|
Use of the Environment |
Environment |
Avoid Dust,oil,corrosive gases |
||
Humidity |
40-90%RH |
|||
Temperature |
0-50℃ |
|||
Tremor |
5.9m/s*s Max |
|||
|
Microstep Dirver DM556 | ||||
Specifications | ||||
Name |
DM556 Stepper Motor Driver |
|||
Microstep |
256 |
|||
Description |
Min |
Typical Value |
Max |
|
Input Supply Voltage VDC |
20 |
20 |
50 |
|
Output Current(Peak Value) A |
1.4 |
1.4 |
5.6 |
|
Logic Control Input Current (mA) |
7 |
7 |
16 |
|
Stepping Impulse Response Frequency(khz) |
0 |
0 |
200 |
|
Insulaion Resistance |
500 |
500 |
- |
|
Cooling Method |
Free Cooling or Forced Air Cooling |
|||
|
Use of the Environment |
Environment |
Avoid Dust,oil,corrosive gases |
||
Humidity |
40-90%RH |
|||
Temperature |
0-50℃ |
|||
Vibration |
10-55Hz/0.15mm |
|||
Storage Temperature |
-20~65℃ |
|||
Weight |
0.25KG |
|||
|
Microstep Driver TB6600 | |
Specification | |
Name |
TB6600 Stepper Motor Driver |
Voltage |
9-42VDC |
Current |
0.5-3.5A |
Microstep |
1-32 |
Cooling Method |
Free Cooling or Forced Air Cooling |
Occasion |
Can not be placed next to other heating equipment,to avoid dust, oil, corrosive gas,high humidity and strong eathquake places, prohibit, prohibit flammable gas and conductive dust, |
Humidity |
40-90%RH |
Shock |
10-55Hz/0.15mm |
|
Storage Temperature |
-20-65℃ |
Weight |
0.15KG |
|
Driver YS-DIV268N-5A | ||||
|
Instruction |
Minimum Value |
Typical Value |
Maximum |
Unit |
|
|
0.2 |
- |
5 |
A |
|
Input Power Supply Voltage |
12 |
24 |
48 |
VDC |
|
Logic Input Current |
7 |
10 |
16 |
mA |
|
Pulse Frequency |
0 |
- |
32 |
kHZ |
|
Insulation Resistance |
500 |
- |
- |
MΩ |
|
Specification | |
Cooling Method |
Free Cooling or Forced Air Cooling |
Occasion |
Can not be placed next to other heating equipment,to avoid dust, oil, corrosive gas,high humidity and strong eathquake places, prohibit, prohibit flammable gas and conductive dust, |
Temperature |
0-+50℃ |
Humidity |
40-90%RH |
Shock |
10-55Hz/0.15mm |
|
Storage Temperature |
-20-65℃ |
Weight |
0.25KG |
(Application scenarios)
✅ Desktop CNC engraving machine: used for woodworking, circuit board, and advertising mold production.
✅ Small CNC milling machine: Processing and model making of lightweight metals such as aluminum and copper.
✅ High precision 3D printers (CoreXY, i3, and other structural upgrades).
✅ Laser cutting/engraving machine.
✅ Automation equipment: such as sorting machines, feeding devices, etc
